16 Port Outdoor Wall Mount Fiber Optic Splitter Box IP65 PC+ABS Plastic NAP

Description

SC APC Plastic FTTH outdoor fibre distribution box optic junction box
Gray/Black/white 16 Port Outdoor Wall Mount Fiber Optic Splitter Box IP68 PC+ABS Plastic NAP

FDB Optical Terminal Box

Product Description

Specification
Model	FDB0216G	CTN qty	10pcs
Size	293*219*84mm	N.W/G.W	13.5kg/16.4kg
Max Capacity	16SC/32LC/1*16 PLC splitter	Ctn size	51*33.5*68cm
Working temperature	-40°C~+75°C	Insertion los	≤0,2dB
Relative humidity	≤85%(+30°C)	UPC return loss	≥50dB
Atmospheric pressure	70KPa~106KPa	APC return loss	≥60dB

Features

The high strength plastic, anti-ultraviolet radiation and ultraviolet radiation resistant, resistant to rain

For indoor and outdoor overhead wall mount or pole mount or aerial mount use

Box of body use "lock type" structure, box of body switching of simple, convenient, with a lock function, safe use

Besides the key lock, there are two buckles to be designed to close the box.

Melt receive flip type design simple to use, melting with complete separation of fine points fibre layout more reasonable

Double layer tray, upper layer for fiber optic adapters, lower layer for splitter routing(as above).

Maximum hold 16pcs SC simplex adapters, or LC duplex adapters.

Can hold 1x2,1x4,1x8,1x16 PLC splitter micro module steel tube

2 inputs ,16 outputs for drop cable,there is cable fixtures and rubber seal to hold the cable entry and exit.
